Hisun Elite – Fully Electric Lithium Iron Battery UTV
This vehicle is based on the proven Hisun E1 platform, professionally upgraded by EMVC with our NZ-made lithium battery system. It offers improved performance, longer lifespan, and the option to customise with accessories such as full cab kits, front trays, or flat decks. Built tough for New Zealand conditions.
Price on application – options available
Powertrain & Motor
- Motor: AC Motor, Nominal 5kW / Peak 30HP
- Torque: 298 Nm
- Drive: Direct final drive with three forward gears for efficient power use
- Top Speed: Up to 45 km/h (subject to conditions)
- Drive System: 2WD / 4WD with front locking differential
Battery System
- Chemistry: Lithium Iron Phosphate (LiFePO₄)
- Capacity: 48V, 200Ah (9.6 kWh)
- Range: Approx. 85 km per battery (subject to operating conditions)
- Design: NZ-made, stainless steel modular casing – no maintenance required
- Swappability: Batteries can be replaced in under 1 hour
- Battery Slots: Space for 2 batteries under seats
- Energy Use: Can be used as a power store for other applications
- Charging: Charge anytime when not in use (no memory effect)
- Charger: 1.2kW onboard charger with cable included
- More Info: See EMVC Battery Product Page
Chassis, Suspension & Braking
- Suspension: Dual A-Arm front and rear with hydraulic shocks + nitrogen assist
- Brakes: 4-wheel ventilated hydraulic disc brakes with regenerative braking
- Ground Clearance: 285 mm
- Tyres: 26 × 9 × 14 (front), 26 × 11 × 14 (rear)
- Wheels: Aluminium
Size & Capacity
- Overall Dimensions: 2,717 mm (L) × 1,885 mm (H) × 1,650 mm (W at front wheels)
Standard Features
- Roof
- Polycarbonate windshield
- Mirrors
- Tow bar
- Rear tipping tub-style cargo deck with gas assist
Optional Add-ons
- Glass windscreen with wiper and washer
- Polycarbonate rear panel
- Front tray
- Full cab enclosure
- Flat deck with drop sides
Warranty
- Battery: 5-year warranty (swap/repair service available in NZ)
- Drivetrain: 3-month warranty
- All other parts: 2-year warranty (excludes consumables)
- Service: Must use approved service agents; conditions apply
Maintenance & Support
- Regular maintenance includes oil, grease, brakes, cleaning, and adjustments
- Refer to the owner’s manual for full details
- EMVC stocks parts locally and can courier from China if needed
- Batteries are maintained and repaired in NZ on a swap basis
- 5-year lease options available
